Natural Rubber Boat Lift Float Bags Marine Salvage Airbags Cylindrical Shape
Product Details:
Place of Origin: Qingdao, China
Brand Name: LuHang
Certification: CCS/BV/ABS/SGS
Model Number: LH1815
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: To be negotiated
Packaging Details: Folded and Packed on Pallet
Delivery Time: 10-15 work days
Payment Terms: T/T, L/C
Supply Ability: 200 Units Per Month
Contact Now
Detailed Product Description
Material: Natural Rubber And Carbon Application: Vessel Launching And Docking
Feature: Strong, Air Tight, Wearable, High Safety Warranty: 1 Year
Lifespan: 6 Years Size: 2m X 12 Or As Per Requirement
Layers: 5 Layers To 12 Layers Working Pressure: 0.12mPa
Safety Parameter: 4.5 Times Item: 18M Dia 15M Long 8 Layers Marine Rubber Airbags For Vessel Launching And Docking
High Light:

airbags for shipping containers

,

boat recovery airbags

18M Dia 15M Long 8 Layers Marine Rubber Airbags for Vessel Launching and Docking



As a professional and experienced manufacturer of marine airbags, Qingdao Luhang Marine Airbag and Fender Company has been devoted itself to developing and producing marine airbags for vessel launching and docking.

Marine airbags are idely used for launching and docking vessels in shipyards, specially medium and small shipyards alongside rivers and seasides in Asian and American countries. Marine airbags are often called ship launching airbags that indicates the most popular application of these heavy duty airbags is for ship launching. It is estimated that more than 80 percent new built ships who’s DWT below 60,000 are launched by marine airbags.





Construction and Structure of Marine Rubber Ship Launching Airbags

Marine rubber airbag typically has a body of cylindrical shape and two conical heads, one at each end. At each head end, there is a metal bushing as a mouth for air inflation and the plug with a ring.

Please refer to the drawing of a typical marine airbag and its accessories below to know the structure and accessories.

Natural Rubber Boat Lift Float Bags Marine Salvage Airbags Cylindrical Shape 0

Natural Rubber Boat Lift Float Bags Marine Salvage Airbags Cylindrical Shape 1

How to select marine rubber airbags for ship launching and docking

Ship launching airbags can be made into various sizes and layers accoding to the ship size and weight and the launching or docking conditions.

Effective length:

The effective length should be same as the ship breadth, or 1 meter shorter than the breath.

We can make airbags in length from 5m to 24m.

Diameter:

Select diameter based on the ship size and work requirement. Select bigger airbags for large ships, but smaller airbags for small boats. In case the ships need cleaning or repairing bottom, choose bigger airbags so that workers can work in a more comfortable posture under the ship. Diameter of 1.5m, 1.8m, 2m or 2.5m are all suitable and available for large ships.

The number of layers:

The more layers the airbag has, the bigger bearing capacity it has. To lift a ship to a certain height, enough airbags with enough layers are needed. Generally speaking, airbags with 6 layers are enough for most engineering works. Only in some rigorous situation, airbags will need 7-8 layers to enhance its performance. For example, if people use airbags to lift heavy caisson but their contact area is limited, and then airbags will need higher pressure and more plies to ensure the safety.

Good selection of marine airbags is vital for the success of marine projects. Get basic knowledge of marine airbags selection then consult with manufacturers can help people complete projects in shortest time.

Below is a chart for the bearing capacity of several sizes

Model Dia Effective Length Overall Length Cord Layer Rubber Plate Thickness Working Pressure Bursting Pressure Lifting Height Bearing Capacity
  M M M Layer Layer mm MPa MPa M Ton/meter Ton/airbag
LH-6 1.2 12 14 6 1 7.2 0.17 0.75 0.90 7.85 94.20
1.00 5.23 62.76
1.10 2.62 31.44
LH-7 1.5 15 17 7 1 8.2 0.16 0.70 1.00 12.21 183.15
1.10 9.77 146.55
1.20 7.33 109.95
1.30 4.89 73.35
LH-8 1.8 18 20.5 8 1 9.2 0.15 0.67 1.20 13.96 251.28
1.30 11.63 15.12
1.40 9.31 167.58
1.50 6.98 125.64
1.60 4.65 83.70
LH-10 2.0 20 23 10 1 11.2 0.17 0.75 1.30 18.32 366.40
1.40 15.70 21.98
1.50 13.09 261.80
1.60 10.47 209.40
1.70 7.85 157.00



In case you are not sure of the suitable sizes and sufficient layers of a launching project or ships, you are welcome to consult us for information. You need provide us with following information:

Ship size: breadth (width) and Length

Ship weight: weight of vessel without cargo is better

Lifting height: the maximum height to lift the ship from the ground

The slipway condition: the declining angel, the ground condition etc.



Please do not hesitate to send us any inquiry here, which will be answered as soon as possible.



Natural Rubber Boat Lift Float Bags Marine Salvage Airbags Cylindrical Shape 2
