Marine EVA Foam Filled Fenders- is type marine fenders and floating fenders system for ships mooring/berth. Foam fenders adopt pure polyurea technology combined with foam, plastic to ensure it float on water, widely applied to construction fields and marine industry. Foam filled marine fenders is constructed with closed cell EVA/PE foam core, sprayed pure polyrea polyurethane elastomer PU skin, reinforced with tough middle nylon layers, with a higher buoyancy itself. Foam filled fenders come with low hull pressure and maintenance, performed better for light weight ships.
Features of MAX Foam Filled Fender
1. Great Floating Performance, not influenced by tidal waves
2. Bright Colours are available upon customer request (not all)
3. No air inflation needed (as compared to pneumatic fenders)
4. High Energy Absorption
5. Reasonably resistant to acid and alkali
6. Good Angular Performance
7. Strong & safe
8. Extremely long lifetime
Speccifications And Performance
Foam-filled fenders are able to absorb 40% more energy than similar sized pneumatic fenders and their gently sloping reaction force curve provides 'softer' docking operations compared to buckling type fendering systems. This results in reduced stresses on docks, wharves, piers and vessels.
Luhang Marine Foam Fenders covers various standard sizes as below. Besides, we can develop and design customized sizes and shapes for special fendering system.
Size (m)
At 60% Compression
Dia
Length
Force Reaction (KJ)
Energy Absportion (KN)
0.50
1.00
8.00
71.00
0.70
1.50
27.00
61.00
1.00
1.50
49.00
205.00
1.20
2.00
93.00
337.00
1.35
2.50
145.00
463.00
1.50
3.00
273.00
696.00
2.00
3.50
456.00
990.00
2.50
4.00
781.00
1386.00
2.50
5.00
985.00
1750.00
3.00
5.00
1410.00
2050.00
3.00
6.00
1695.00
2460.00
3.30
6.50
2245.00
2950.00
4.50
9.00
7660.00
19650.00
EVA Foam Filled Marine Polyurethane Fender Characteristics
1.Similar to general compression fenders, solid foam filled polyurethane fenders have floating performance.
2.Compared with pneumatic fenders, they possess better energy absorption performance and low reaction performance.
3.Unlike pneumatic fenders, they do not require checking or inflating and are maintenance-free.
4.There is no explosion risk and they are safe.
Vessel Polyurethane Floating Fender Range of Use
1.For marine terminal fenders.
2.Suitable for gravity and London Wharf, especially docks with large tidal ranges.
3.Particularly applicable to ship-to-ship fenders. Floating fenders have greater adaptability.
4.As pier fenders, they protect bridge piers and ships from damage.
EVA Foam Filled Polyurethane Floating Fender Advantages
1. The polyurethane floating fender has floating properties and is resistant to tidal ranges.
2. The EVA foam filled polyurethane fender has bright colors and can provide products in various colors as requested.
3. There is no air, making it resistant to tidal ranges.
