High Strength Marine Floating Bumper For Safety Station Berthing Fender

High Strength Marine Floating Bumper For Safety Station Berthing Fender

    • High Strength Marine Floating Bumper For Safety Station Berthing Fender
    • High Strength Marine Floating Bumper For Safety Station Berthing Fender
  • High Strength Marine Floating Bumper For Safety Station Berthing Fender

    Product Details:

    Place of Origin: CHINA
    Brand Name: LUHANG
    Certification: CCS,BV,LR,ABS
    Model Number: EVA

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiable
    Packaging Details: Pallet
    Delivery Time: 5 work days
    Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram
    Supply Ability: 300 Units Per Month
    Contact Now
    Detailed Product Description
    Material: EVA Foam + PU Skin Specification: D3.0m X L5.0m
    Energy Absorption: 1410 KJ Reaction Force: 2050 KN
    Standard: ISO 17357 Application: Marine Protective Bumper
    High Light:

    cell foam fender


    foam filled boat fenders

    D3.0m x L5.0m Marine Floating Bumper EVA Foam Filled Fender For Dock


    Marine Bumper - Poly Urea Coated Skin EVA Foam Filled Fender Marine Bumper


    EVA solid PU coated fender is a fender using light and elastic foam as a bumping media . EVA foam is featured with environment protection , high elasticity , high adhesion . Outside coated with PU which is anti-seeping and anti-aging . The material improves the fender’s design life and economic value . EVA foam fender has good softness and high resistance of impact , breaking and low temperature . It’s a better bumper than pneumatic rubber fender . It consists of an outer Polyurethane protective layer , a reinforced rubber nylon cord fabric , as well as an internal space that is filled with foam as a medium to absorb collision . Foam fenders outer layer has an extremely low frictional resistance and is highly resistant to wear due to its strength . Impact force is efficiently absorbed by the foam fender , reducing the resultant force acted upon the wharf/vessel at the point of contact.


    Application wise , EVA foam filled fender can be used for tugs , workboats, pilot boats and is suitable for open sea terminals, gravity ports , especially for large tidal wave docks . Foam fender is also a viable option for Ship-to-Ship (STS) operations .


    Floating EVA foam filled fenders become an ideal ship protection medium used extensively by large tankers, LPG vessels, ocean platforms, large docks, harbour and wharf. Exported to many countries like Germany, Norway, Argentina, Vietnam, Brazil, America, Denmark, Finland, Indonesia, Singapore, Philippines, Belgium, Chile, Colombia, Croatia and more.

    High product quality and reasonable costing drives their adoption in the global market and are increasingly preferred as the No.1 alternative to the Yokohama brand.


    Features of LUHANG Foam Filled Fender

    • Great Floating Performance , not influenced by tidal waves
    • Bright Colours are available upon customer request (not all)
    • No air inflation needed ( as compared to pneumatic fenders )
    • High Energy Absorption
    • Reasonably resistant to acid and alkali
    • Good Angular Performance
    • Strong & safe
    • Extremely long useful life

    Types of Foam Filled Fender

    • Portable Foam Fender (usually small size)
    • Flange Foam Fender (usually for larger dimensions)

    Flange-type foam filled fender can either come in a chain net , a chain net with tires , or without the net (fender body only).


    Normal Kind EVA Foam Filled Fender specifications


    Luhang EVA fender
    Size(mm) compression at 60%
    Diameter length Energy absorption(KJ) Reaction Force(KN)
    300 500 1.8 3.8
    500 1000 8 71
    600 1000 12 86
    660 1100 20 120
    700 1500 27 161
    1000 1500 49 205
    1000 2000 64 274
    1200 2000 93 337
    1200 2400 110 390
    1300 2900 145 463
    1350 2500 145 463
    1500 3000 216 624
    1700 3000 273 696
    2000 2200 286 622
    2000 3500 456 990
    2000 4000 505 1110
    2200 4500 697 1396
    2500 4000 781 1386
    2500 5000 985 1750
    3000 5000 1410 2050
    3000 6000 1695 2460
    3300 6500 2245 2950
    4500 9000 7660 19650


    LUHANG Certification


    LUHANG Company has been Certificated by ISO 9001:2009, CCS, BV, SGS, GL, DNV.

    Passed Environment Management System Certification, and OHSMS Certification.

    LUHANG Products have been approved by CCS, BV, LR, DNV, GL, ABS, V-TRUST and other third party inspector.


    LUHANG Company Information


    Qingdao LuHang Marine Airbag and Fender Co., LTD,foundedin 1988, is the largest marine airbag and fender manufacturer in China.We have established long-term cooperation relationship with central enterprises, many big shipyards and ship owners, trading companies in China. We also export to Malaysia, Indonesia, Philippines, Singapore, India,Vietnam, Turkey etc. and many other countries in the world.
