Heavy Duty Airbags For Lifting

Product Details:

Place of Origin:	Qingdao, China
Brand Name:	Lu Hang
Certification:	CCS/BV/ABS/SGS
Model Number:	LH2540

Payment & Shipping Terms:

Minimum Order Quantity:	1 Unit
Price:	To be negotiated
Packaging Details:	Inflated or Deflated on Pallet
Delivery Time:	10-15 work days
Payment Terms:	T/T, L/C
Supply Ability:	30 Units Per Month

Contact Now

Detailed Product Description

Material:	Mixed Rubber With Natural Rubber And Carbon	Size:	Customize
Color:	Black	Product Name:	Pneumatic Marine Rubber Airbag
Usage:	Ship Launching,ship Rubber Marine Salvage Lift Bags	Certification:	CCS,ABS,BV,LR

Heavy Duty Airbags For Lifting

Description

The heavy duty airbag for lifting is a revolutionary product designed specifically for marine operations and ship - related applications. It is an essential tool that combines the flexibility of rubber with the power of pneumatic technology, offering a wide range of benefits and uses in the maritime industry.

Specifications

Item	Description
Place of Origin	China
Brand Name	Luhang Marine
Model Number	LH2540
Material	Mixed Rubber With Natural Rubber And Carbon
Diameter	0.5m-3.0m, or As Request
Length	1.0m-28.0m, or As Request
Working Pressure	0.05-0.25 mpa
Technics	High pressure, overall winding, explosion-proof
Use	ship launching and docking
Thickness	4-13 ply
Standard	Conducted by ISO14409
Accessories	Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube
Packaging	Inner-Plastic Bag; Outer-Standard Wooden Pallets.
Keywords	Ship launching airbags
Certificates	CCS,ABS,BV,LR
MOQ	1
Usage	Ship Launching,ship Rubber Marine Salvage Lift Bags

Unique Holistic Wrapping Technology

Heavy Duty Airbags For Lifting 0

Mix materials according to the formula

Heavy Duty Airbags For Lifting 1

Closed Refining, Open Refining

Heavy Duty Airbags For Lifting 2

Rubber sheet

Heavy Duty Airbags For Lifting 3

Outer rubber calendering

Heavy Duty Airbags For Lifting 4

Skeleton material calendering

Heavy Duty Airbags For Lifting 5

Apply metal-rubber adhesive (Chemlease) - primer coat in gray color

Heavy Duty Airbags For Lifting 6

Forming

Heavy Duty Airbags For Lifting 7

Detail Handling

Heavy Duty Airbags For Lifting 8

Vulcanization

Heavy Duty Airbags For Lifting 9

Packing After Passing The Inflation Inspection

Heavy Duty Airbags For Lifting 10

Export Pallet Packaging

Heavy Duty Airbag For Lifting Procedure
1.Determine the connection position and method of the salvage airbag.
2.Open the package of the heavy duty airbag for lifting, spread it flat, connect the inflation tube to the airbag, conduct a trial inflation and then deflate it, waiting for use.
3.Hang the airbag on the item to be salvaged.
4.Inflate the airbag slowly.
During the inflation process, the heavy duty airbag for lifting continuously provides buoyancy. Once the buoyancy is greater than the weight of the object, the object will rise rapidly at a very high speed. Underwater personnel should pay attention to safety and ensure the connection strength of the inflation tube.
For a single salvage airbag: Inflate it slowly through pipeline connection.
For multiple salvage airbags: Inflate the first airbag to 80%, then start inflating the next one. After all airbags reach 80%, inflate each airbag to 100% one by one.
