Product Details:
Place of Origin: China
Brand Name: Luhang
Certification: ISO14409
Model Number: LHA1
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: USD180.00 ~ USD4700.00 Negotiable
Packaging Details: Film packing on palllet
Delivery Time: 10 ~ 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100pcs / month
Contact Now
Detailed Product Description
Product Name: Launching Air Bags Material: 60% Nature
Usuage: Ship Boat Launching And Landing Diameter: 0.5m ~ 3.0m
Length: 5m ~ 24m Certificate: ISO14409
Highlight:

inflatable air bags for shipping

,

docking rubber airbags

Ship Launching Airbags Synthetic Rubber Layers Marine Landing Balloons



The inflatable rubber airbag's body is round and smooth and the heads are safe and reliable. Our airbags have been widely used domestically and overseas. The application of airbag has little specific site constraints and it does not large machinery or equipment, thus using airbags to launch or land ships can shorten project period and financially save a large amount.



Flexible balloon like an elastic cushion, it make the hull in the process of launching free pitch, keep the bottom has a larger contact area, makes the stress of the hull very ease, so that the hull structure, on the surface of the paint (coating) will not be damage. The inflatable rubber airbag is designed for launching technology development, the main function is carrying or hauling the ship launching uphill, has a high load capacity, wear resistance and corrosion resistance to seawater.



The outer rubber layer that covers the outside of marine airbag to protect under layers from abrasion and other external forces. This compound has sufficient tensile and tearing strength to withstand any condition and hard usage.



The inner rubber layer seals pressurized air inside marine airbags.



The reinforcement cord layers, which are made of synthetic-tire-cord commonly used in tires, are arranged at ideal angles to hold the internal pressure and distribute stress evenly. So they can provide strong efficient reinforcement.



Flexible Inflatable Marine Airbags Heavy Duty Airbags Wear Resistance For Lifting 0



Performance  of Airbags



Diameter Safe working pressure Work high The bearing capacity
KN/M T/M
D=1.2M 0.14MPa 0.7m 110.07 11.22
0.6m 132.04 13.46
0.5m 154.02 15.7
0.4m 175.99 17.94
D=1.5M 0.11MPa 0.9m 103.79 10.58
0.8m 121.06 12.34
0.7m 138.32 14.1
0.6m 155.59 15.86
0.5m 172.85 17.62
D=1.8M 0.09MPa 1.1m 99.08 10.1
1.0m 113.21 11.54
0.9m 127.33 12.98
0.8m 141.46 14.42
0.7m 155.59 15.86
0.6m 169.71 17.3
D=2.0M 0.08MPa 1.2m 100.65 10.26
1.1m 113.21 11.54
1.0m 125.76 12.82
0.9m 138.32 14.1
0.8m 150.88 15.38
0.7m 163.43 16.66
0.6m 175.99 17.94



The flexibility of marine airbag the contact area will be affected by some terms which include the carried ship condition, the different position from gravity center during the process of ship launching and pulling. So the bearing capacity of airbags will vary as well as the contact area.

The application of rubebr airbag has little specific site constraints and it does not large machinery or equipment, thus using rubber airbags to launch or land ships can shorten project period and financially save a large amount. Through over 20 years’ development and practice, airbag has been approved to be safe, effective, eco-friendly, flexible.


Flexible Inflatable Marine Airbags Heavy Duty Airbags Wear Resistance For Lifting 1
